>4-Panel Cottage Kit (1220W)

Description

1,220 Watt in solar PV, 2kW pure sine-wave inverter.
Produces 3.2 kWh/day in summer, 1.6 kWh/day in winter

4x Trojan L16RE-B-6V 6V battery, RE series, 370Ah/20h capacity, smart carbon, L terminals, 2 + 3 years warranty
3x Battery interconnect 2/0, 12″
1x Littelfuse JLLN-300, 300A/300V class T fuse
4x Hanwha Solar Q.PEAK-G4.1/SC 305 Watt, 60C mono PV module, black frame
1x Multi-Contact 32.0019 PV-AZS4, MC4 Y-connector, (2) male / (1) female, 1000V, 30A
1x Multi-Contact 32.0018 PV-AZB4, MC4 Y-connector, (1) male / (2) female, 1000V, 30A
1x set of MC4 Extension wires for PV module, 15′ PV-Wire
1x EP Solar Tracer-4215BN, 40A MPPT charge controller, 12V/24V, 150V DC
1x EP Solar MT50 remote control, LCD display, flush/surface mount
1x Cotek SP2000-124 pure sine wave inverter 2000W 24V, cUL
1x Inverter cables 2/0 AWG, 10 ft. pair
1x HydroVolt battery hydrometer, Compaselect – the last hydrometer you will ever buy!
1x MidNite Solar MNBCM, battery capacity meter for 12, 24, 36, and 48 volt

All the parts needed to make a simple, yet robust off-grid power system. We supply high-quality parts that should last a long, long time. These may be small systems, but they are real off-grid systems meant for real use (in short, these are not toys).

Our kits include pure-sine inverters. These produce a clean sine wave that runs all AC equipment (unlike the much-cheaper modified sine wave inverters). The inverters can provide twice as much power for short durations, so starting motors (i.e. well pump) and compressors (i.e. fridge) is no problem.

We sell the cottage kits with 1 through 4 panels. The solar panels are the same as used for large grid-tie systems on rooftops; they are very durable (25-year warranty!) and they offer great value for money. The included MPPT controller makes the most of every light situation; even when it is overcast there is usually still lots of Amps coming into the batteries!

Wiring Diagram

Please see the PDF for the wiring diagram for these kits. The large fuse is directly bolted to the positive side of the battery bank, and it is there as a measure-of-last-resort, to prevent the wiring from melting in case of a short circuit. All the other wires (charge controller, inverter, etc.) connect to the other side of that fuse, so those wires are protected to some extend in case of a short.


4-Panel Cottage Kit

System Sizing

What size system you need will depend on your expected daily energy use, and if this also needs to provide energy in winter. To find out how much energy you need, multiply each load in the cottage by the time it is expected to be used on an average day: A 15 Watt light bulb that is switched on for 3 hours uses 3 x 15 = 45 Watt-hours of energy (that’s 0.045 kWh, a kilo-Watt-hour is simply 1000 Watt-hours). Add up all your expected energy use, and then look at our sizing table. We can help you with this.

In our southern Ontario climate the sun produces just about 2.7 kWh per average day for every 1000 Watt of solar panels, from late spring through early fall (that is just about 4 panels). In winter this will produce just about half, or 1.35 kWh per average day. This is for panels that are mounted facing south, at a 45-degree pitch angle. That angle is great if you are going to use one angle for summer and winter, if you want to optimize for one or the other, 30-degrees is optimal for summer, and 60-degrees is great for winter. The latter sheds show very well (panels produce zero, even with a dusting of snow on them, so it is essential to keep them snow-free in winter).

Daily Energy Use (per average day)Panels
SummerWinter
0.8 kWh0.4 kWh1
1.6 kWh0.8 kWh2
2.4 kWh1.2 kWh3
3.2 kWh1.6 kWh4



The inverter size is determined by all the equipment that you expect to have switched on at the same time (plus anything that switches on at unpredictable times, such as a fridge).

The cottage kits are sized for the most common energy needs found at small cottages. We can also design a system specifically for your off-grid home or cottage, just contact us.

Specifications

Solar power

Controller type

Max. current

Battery Voltage

Amp-hours (20-hour)

Output power

AC Voltage

1 review for 4-Panel Cottage Kit (1220W)

  1. Rated 5 out of 5

    GreatNorthZ

    Purchased this kit a couple months ago. Very happy with the whole experience of solacity. The staff is very knowledgeable and always willing to answer questions or concerns. The products in this kit are all of good quality and contains everything needed. We purchased our kit to basically do 2 things at our cottage.
    1 run a full size 16 cu/ft energy star fridge 350 kwh/yr rated.
    2. Lighting about 6 LED bulbs to light the cottage and one deck.
    The system handles this flawlessly. The cottage is generally used for 2 or 3 days at a time. With the 4 panels it keeps the battery bank charged well. I will say our roof top instalation is as ideal as it gets for a fixed panel set up.
    Instalation was easy and straight forward. The panel tracking and attaching the panels was much easier than expected.
    Our cottage was previously propane for fridge and lighting. Our propane fridge quit working and the price of a new propane fridge was not that far off of what this whole solar kit cost to buy.
    Wish we made the move to solar years ago. Would recomended this kit to anyone. Not one complaint with the product or service 100% satisfied.
