>>>APsystems YC500A

APsystems YC500A


APsystems YC500A, dual micro-inverter, 500W, 240V AC, for 60- and 72-cell modules

SKU: APS-229-100 Categories: , Tags: ,


APsystems is the fastest growing brand of micro-inverters, currently no.2 worldwide! Their micro-inverters have gained a reputation as extremely reliable, and because no expensive trunk cable is needed, the overall system cost is lower than with other micro-inverter brands. Monitoring, with APs’ gateway, is provided through Web or smartphone.

The YC500A micro-inverter handles two PV modules simultaneously with dual MPPT inputs. Simply click the panel wires into the unit, and extend the build-in trunk cable to the next micro-inverter. Up to 14 solar modules (7x YC500s) can be installed in a string with a single 20A breaker.

Because the units provide module-level ground-fault protection code does not require rapid-shutdown or squirrel guard to be installed. This makes installations faster, cheaper, and much better looking!


  • Maximizes energy production
  • Minimizes impact of shading, dust, and debris
  • Recommended for up to two 320 watt 60-cell or 72-cell modules
  • No single point of system failure
  • No DC design or string calculation required
  • Maximum power output 500 Watt (from two PV modules)
  • Up to 7 units (14 PV modules) per string
  • Standard warranty of 10 years, with 25-year extension optional
  • Operating temperature range of -40C to +65C!
  • cUL listed for Canada




Mnfr. model

Output power

AC Voltage


No. of MPPT

Max. Voltage

MPPT Voltage range


Ground-fault (GFCI)

Temperature range
