Lorentz PS150-C KIT

The Lorentz PS150-C KIT is a submersible solar pump, centrifugal type, for flow rates up to 5.0 m³/h (21 GPM) and lifts up to 20 meters (65 feet). Fit for 12 to 24V systems (1-2 solar modules or batteries in series). This pump can be used as a submersible pump or as a floating pump. It is an ideal solution for a variety of applications such as: Aeration, drinking water supply, livestock watering, pond management, and irrigation.

PS150-C KIT is more powerful, energy efficient, quieter and much more durable than other pumps in this range. The motor is brushless and maintenance free. The kit contains a solar controller, motor, and pump end.

Features

PS150 Controller

• Controlling of the pump system and monitoring of the operating states
• Charge controller included
• Mounted at surface (no submerged electronic parts)
• Two control inputs for well probe (dry running protection), float or pressure switches, remote control
• Automatic reset 20 minutes after well probe turns pump off
• Protected against reverse polarity, overload and high temperature
• Speed control, max. pump speed adjustable to reduce flow rate to approx. 30 %
• Solar operation: Integrated MPPT technology
• Battery operation: Low voltage disconnect and restart after battery has recovered
• Max. efficiency 92 % (motor + controller)
• Enclosure: IP 54 (sealed, weatherproof)

ECDRIVE 200-C Motor

• Brushless DC motor
• Water filled
• No electronics in the motor
• Submersion max. 250 m
• Premium materials

Pump End

• 10 cm / 4″ well diameter
• High life expectancy
• Non-return valve
• Premium materials
• Dry running protection (optional)
