Description

The MP (Magnum Panel) enclosures have been specifically designed to combine all of the major components required for a high power renewable energy system – inverter/battery disconnect, AC overcurrent protection, grounding connections, and a full system inverter bypass switch as a convenient way to isolate the inverters for battery maintenance – into easy to install pre-wired enclosures.

This panel is designed to accommodate one to three inverters

Features

  • More power capacity: the 125A bypass breaker and the 1000A DC shunt safely handle the power from larger systems.
  • Expandable: start with the enclosures and just two inverters and in the future expand to up to four inverters, using the MPX.
  • Easy installation: all connections are frontmounted, including AC and DC breakers and the MPX.
  • Labor saving: panel is prewired for fast installation, saving labor costs.
  • DC load breakers: fits either din rail or backmount DC load breakers.
  • Convenient knockouts: knockouts on the side of the enclosures are compatible with charge controllers.
  • Separate AC and DC enclosures: for installers who prefer separate enclosures, the MPDH provides an easy solution.

Includes

  • Two DC breakers – 250A
  • One 125A AC bypass breaker
  • 1000A/100mv DC shunt
  • Inverter AC input protection
  • MPX extension includes AC/DC circuit protection and wiring
